Description
| Product | PGE-2-12 | PGE-5-26 | PGE-8-14 | PGE-15-10 | PGE-15-26 | PGE-50-26 | PGE-50-40 | PGE-100-26 |
|---|---|---|---|---|---|---|---|---|
| Gripping force (per jaw) | 0.8–2 N | 0.8–3.5 N | 2–8 N | 6–15 N | 6–15 N | 15–50 N | 15–50 N | 30–50 N |
| Stroke | 12 mm | 26 mm | 14 mm | 10 mm | 26 mm | 26 mm | 40 mm | 26 mm |
| Recommended workpiece weight | 0.05 kg | 0.1 kg | 0.1 kg | 0.25 kg | 0.25 kg | 1 kg | 1 kg | 2 kg |
| Opening/Closing time | 0.15 s / 0.15 s | 0.3 s / 0.3 s | 0.3 s / 0.3 s | 0.3 s / 0.3 s | 0.5 s / 0.5 s | 0.45 s / 0.45 s | 0.6 s / 0.6 s | 0.5 s / 0.5 s |
| Repeat accuracy (position) | ±0.02 mm | ±0.02 mm | ±0.02 mm | ±0.02 mm | ±0.02 mm | ±0.02 mm | ±0.02 mm | ±0.02 mm |
| Noise emission | < 50 dB | |||||||
| Weight | 0.15 kg | 0.4 kg | 0.4 kg | 0.155 kg | 0.33 kg | 0.4 kg | 0.46 kg | 0.55 kg |
| Driving method | Rack & pinion + Cross roller guide | Rack & pinion + Cross roller guide | Rack & pinion + Linear guide | Precision planetary reducer + Rack and pinion | Precision planetary reducer + Rack and pinion | Precision planetary reducer + Rack and pinion | Precision planetary reducer + Rack and pinion | Precision plane reducer + Rack and pinion |
| Size | 65 × 39 × 18 mm | 99 × 55 × 26 mm 113.5 × 55 × 26 mm (brake) | 97 × 62 × 31 mm | 89 × 30 × 18 mm | 86.5 × 55 × 26 mm 107.5 × 55 × 26 mm (brake) | 97 × 55 × 29 mm 118 × 55 × 29 mm (brake) | 97 × 55 × 29 mm 118 × 55 × 29 mm (brake) | 125 × 57 × 30 mm |
| Communication interface | Standard: Modbus RTU (RS485), Digital I/O Optional: TCP/IP, USB2.0, CAN2.0A, PROFINET, EtherCAT | |||||||
| Rated voltage | 24 V DC ± 10% | |||||||
| Rated current | 0.2 A | 0.4 A | 0.4 A | 0.14 A | 0.22 A | 0.5 A | 0.5 A | 1.2 A |
| Peak current | 0.5 A | 0.7 A | 0.7 A | 0.22 A | 0.5 A | 0.8 A | 0.8 A | 2.4 A |
| IP class | IP40 | |||||||
| Recommended environment | 0~40°C, under 85% RH | |||||||
| Certification | CE, FCC, RoHS | |||||||
