Description
Specifications
| Number of Axis | 4 |
|---|---|
| Payload | 500 g |
| Max. Reach | 320 mm |
| Repeatability | ±0.2 mm |
| Communication | USB / Wi-Fi* / Bluetooth* |
| Power Supply | 100V – 240V, 50/60 Hz |
| Power In | 12V / 6.5A DC |
| Consumption | 78W Max |
| Working Temperature | -10° – 60° C |
Axis Movement
| Axis | Range | Max Speed (250 g workload) |
|---|---|---|
| Joint 1 base | -120° ~ +120° | 320° / s |
| Joint 2 rear arm | -5° ~ +90° | 320° / s |
| Joint 3 forearm | -15° ~ +90° | 320° / s |
| Joint 4 rotation servo | -140° ~ +140° | 480° / s |
Endeffectors
| Component | Specification |
|---|---|
| 3D Printer Kit |
|
| Laser |
|
| Pen Holder | Pen Diameter: 10 mm |
| Vacuum Suction Cup |
|
| Gripper |
|
