Delta · AC drives (VFD)

Delta compact AC drives (VFD)

Compact Delta variable frequency drives for general machines, conveyors, fans and pumps. Ausweg supplies, programs and supports them as an authorised Delta channel partner in Coimbatore and Bangalore.

Request a quoteCompare the range
  • 4 products on one page
  • Selection, integration & support
  • Coimbatore · Bangalore
Delta compact AC drives (VFD)
The range at a glance

Small drives, full Delta drive technology

  • MS300: standard compact vector drive for IM and PM motors, with STO safety.
  • ME300: the same technology in a body 60% smaller.
  • VFD-E and VFD-EL-W: micro and compact drives, the VFD-E with a built-in PLC.
ProductWhat it is
MS300 Compact Vector AC DriveStandard compact vector drive for IM and PM motors, with STO safety
ME300 Compact AC DriveCompact vector drive 60% smaller, for IM and PM motors
VFD-E Sensorless Vector Micro DriveSensorless vector micro drive, IP20, with built-in PLC function
VFD-EL-W Compact Vector DriveNew-generation compact vector drive, simple and durable
Product details

The full Delta compact AC drives (VFD) range

Delta MS300 Compact Vector AC Drive
AC drives (VFD)

Delta MS300 Compact Vector AC Drive

Delta’s MS300 series is a standard compact vector control drive that inherits Delta’s superior drive technology.

  • Supports Open loop control of IM and PM motors
  • Output frequency: Standard models: 0 to 599 Hz
  • High speed models: 0 to 1,500 Hz (V/f control for IM motor only)
  • 120% for 60 seconds for Normal Duty (ND)
Full specifications
  • Supports Open loop control of IM and PM motors
  • Output frequency: Standard models: 0 to 599 Hz
  • High speed models: 0 to 1,500 Hz (V/f control for IM motor only)
  • 120% for 60 seconds for Normal Duty (ND)
  • 150% for 60 seconds for Heavy Duty (HD)
Request a quote →
Delta ME300 Compact AC Drive
AC drives (VFD)

Delta ME300 Compact AC Drive

Delta’s ME300 Series is a new generation compact vector control drive that inherits Delta’s superior drive technology, but with a 60% reduction in size.

  • Supports IM / IPM / SPM motors and VF / SVC control
  • Dual rating design: Normal Duty (ND), 120% for 60 seconds or 150% for 3 seconds
  • Heavy Duty (HD), 150% for 60 seconds or 200% for 3 seconds
Full specifications

With its user-friendly operation, ultra-compact size, quick installation, and flexible, durable design, the ME300 is your key to increased market competitiveness and greater success.

  • Supports IM / IPM / SPM motors and VF / SVC control
  • Dual rating design: Normal Duty (ND), 120% for 60 seconds or 150% for 3 seconds
  • Heavy Duty (HD), 150% for 60 seconds or 200% for 3 seconds
Request a quote →
Delta VFD-E Sensorless Vector Micro Drive
AC drives (VFD)

Delta VFD-E Sensorless Vector Micro Drive

Sensorless Vector AC Micro Drive. The VFD-E series represent Delta Electronics low horsepower, constant torque, IP20 rated Drive.

  • Output frequency: 0.1~600Hz
  • Design: Modular & compact
  • PLC: Built-in PLC function
  • EMI Filter: Built-in (230V 1 phase / 460V 3 phase)
Full specifications
Specifications
Output frequency0.1~600Hz
DesignModular & compact
PLCBuilt-in PLC function
EMI FilterBuilt-in (230V 1 phase / 460V 3 phase)
Fieldbus ModulesOptional (DeviceNet, Profibus, LonWorks, CANopen)
RFI-switchIncluded for mains
DC BUS sharingEasy
ExtensionFlexible
ProtectionComplete
Request a quote →
Delta VFD-EL-W Compact Vector Drive
AC drives (VFD)

Delta VFD-EL-W Compact Vector Drive

Delta’s VFD-EL-W series is the new generation compact vector control drive. Simple, delicate and durable design inherits Delta’s superior drive technology.

  • Design: Compact, simple and durable design.
  • Control Modes: Multi-speed operation and control mode: digital panel, external terminal and Modbus communication.
  • Pump Control: Multi-pump control; PID Control.
  • Drive Support: Supports one drive with two motors in parallel and Time Out Detection function.
Full specifications

– Various essential functions are built-in as standard, including: Multi-step Operation; Torque Compensation; PID Control; Multi-Pump Control; Water Supply at Constant Pressure; Leakage Detection function and so on.

– It also with complete built-in protection mechanism, such as: Over-current; Over-voltage; Low-voltage; Over-heat; Over-load; Over-torque; Phase Loss Protection and so on.

VFD-EL-W not only saves the extra cost but also increase the market competitiveness with the best technics.

Specifications
DesignCompact, simple and durable design.
Control ModesMulti-speed operation and control mode: digital panel, external terminal and Modbus communication.
Pump ControlMulti-pump control; PID Control.
Drive SupportSupports one drive with two motors in parallel and Time Out Detection function.
Overload CapacityHigh overload capacity, 150% rated current for 1 min.
CertificationCE, RoHS, GB12668.3
Request a quote →

Specifications are from Delta Electronics and may change. Ask us for the latest datasheet, price and availability.

Why buy Delta from Ausweg

More than a supplier

From Coimbatore, Bangalore and Chennai we help you choose, install and run the right product, and support it after go-live.

Selection & sizing

The right model and rating for your load, duty cycle and budget.

Programming & commissioning

PLC, HMI, drive and servo programming with on-site start-up.

Control panels

Panels designed, wired and tested in-house around Delta products.

Local support

Engineers, service and spares from our Coimbatore and Bangalore offices.

Related series

More from Delta

View all Delta products
Delta high-performance and application drives
4 products · comparison table

Delta high-performance and application drives

Delta drives built for demanding control and specific applications: precise vector control, fans and pumps, textile and…

Compare the range →
Delta ASDA servo drives and motors
5 products · comparison table

Delta ASDA servo drives and motors

Delta ASDA AC servo systems for positioning, motion and machine building, from high-performance to cost-effective…

Compare the range →
Delta sensors, meters and controllers
3 products · comparison table

Delta sensors, meters and controllers

Delta devices that measure: power meters for energy monitoring, laser displacement sensors for dimensions, and modular…

Compare the range →
Delta

FAQ

Still unsure? Ask an engineer.

Which Delta compact drive should we choose?

MS300 for most standard machines, ME300 where panel space is tight, VFD-E for simple machines that benefit from a built-in PLC. We size the drive from the motor rating and load.

Does Ausweg program and commission Delta drives?

Yes. We size, supply, program and commission Delta drives, and build the control panels around them.
